TAF-P-7.5A

General Information
Specification

မန္တလေးမြို့တွင်း 𝐀𝐫𝐞𝐚 များနဲ့ ရန်ကုန်မြို့ သတ်မှတ်မြို့နယ် 𝐀𝐫𝐞𝐚 များကို 𝐃𝐞𝐥𝐢𝐯𝐞𝐫𝐲 𝐅𝐫𝐞𝐞 ၊ 𝐈𝐧𝐬𝐭𝐚𝐥𝐥𝐚𝐭𝐢𝐨𝐧 𝐂𝐡𝐚𝐫𝐠𝐞𝐬 𝐅𝐫𝐞𝐞 နဲ့ ပို့ဆောင်ပေးပါသည်။ နယ်မှ ဝယ်ယူသူများအတွက် ကားဂိတ်သို့ ပို့ဆောင်ပေးပါသည်။

Technical Specification
Power 7.5 kVA
Duty Prime
Control Panel Options Available for AMF / Manual Control
Acoustic Insulation PU FR – Acoustic Foam
Dimensions (Length) 1500 mm
Dimensions (Breadth) 850 mm
Dimensions (Height) 1250 mm
Fuel Tank Capacity * 50 L
Weight ** 700 kg
ENGINE
Engine Manufacturer TAFE Motors and Tractors Limited
Engine Brand TAFE POWER
Engine Model 198 ES
Cylinders 1
Aspiration Naturally Aspirated
Engine BHP (gross) 11.5
Reference Standard Engine – BS: 5514, ISO : 3046, IS 10000, Genset – ISO: 8528
Displacement 981 cc
Compression Ratio 17.5:1
Type / Class of Governing Mechanical / A1 (As per BS 5514)
Bore x Stroke 100 x 125 mm
Type of Cooling Air Cooled
Lub Oil Sump Capacity (With Filters) 5
Engine Electrical System 12 Volts DC
ALTERNATOR
Brand Stamford / Leroy Somer
Phase 1 Phase / 3Phase
Voltage 220, 230, 240 V AC / 380, 400, 415 V AC
Power Alternator Type Single Bearing, Brushless, Single / Three Phase, Insulation Class H
Power Factor 0.8 lag
Rated Speed / Frequency 1500 RPM, 50 Hz / 1800 RPM, 60 Hz
